Video Signal Converters

Matrox ConvertIP DRS. Housing material: Metal. Supported chroma subsampling: 4:2:2, 4:4:4, 4:2:0, Color space supported: RGB, YUV, Maximum refresh rate: 60 Hz. Input voltage: 12 V, Power consumption (typical): 18 W. Width: 7.52" (191 mm), Depth: 7.13" (181 mm), Height: 1.42" (36 mm)

Matrox ConvertIP DSH. Housing material: Metal. Supported chroma subsampling: 4:2:2, 4:4:4, 4:2:0, Color space supported: RGB, YUV, Maximum refresh rate: 60 Hz. Input voltage: 12 V, Power consumption (typical): 18 W. Width: 7.52" (191 mm), Depth: 7.13" (181 mm), Height: 1.42" (36 mm)

Matrox ConvertIP SRH. Housing material: Metal. Supported chroma subsampling: 4:2:2, 4:4:4, 4:2:0, Color space supported: RGB, YUV, Maximum refresh rate: 60 Hz. Input voltage: 12 V, Power consumption (typical): 18 W. Width: 5.43" (138 mm), Depth: 7.13" (181 mm), Height: 1.42" (36 mm)

Sony BKMFW16. Product color: Silver, Compatible products: GXD-L52H1

ATEN VC486. Product color: Black, Housing material: Metal. Maximum video resolution: 3840 x 2160 pixels, Supported video modes: 720p, 1080i, 1080p, 2160p, Serial Digital Interface (SDI) standard: SMPTE 292M, SMPTE 424M, SMPTE 425M, SMPTE ST-2081, SMPTE ST-2082. Line-out balanced impedance: 75 Ω. Host interface: SDI, Output interface: HDMI, Video in: SDI. Input voltage: 5 V, Operating voltage: 5 V, Operating current: 3 A

ATEN VC480. Product color: Black. Host interface: BNC, Output interface: HDMI, BNC. Input voltage: 5 V. Width: 4.28" (108.7 mm), Depth: 4.84" (123 mm), Height: 1.2" (30.5 mm)

ATEN VC840. Product color: Black. Host interface: HDMI, Output interface: BNC. Input voltage: 5 V. Width: 4.21" (107 mm), Depth: 4.81" (122.2 mm), Height: 1.2" (30.4 mm)

ATEN VC182. Product color: Black. Maximum video resolution: 1920 x 1200 pixels, Supported video modes: 1080p. Host interface: HDB-15, RCA, Output interface: HDMI. Input voltage: 5 V. Width: 3.27" (83 mm), Depth: 4.33" (110 mm), Height: 1.1" (28 mm)

ATEN VC812. Product color: Black. Maximum video resolution: 1920 x 1200 pixels, Supported video modes: 1080p. Host interface: HDB-15, RCA, Output interface: HDMI. Width: 3.27" (83 mm), Depth: 4.33" (110 mm), Height: 1.1" (28 mm)

ATEN VC1280. LED indicators: Power, Product color: Black, Housing material: Metal. Maximum video resolution: 3840 x 2160 pixels, Video resolutions: 1920 x 1200,3840 x 2160 pixels. Output interface: HDMI, Video in: HDMI, VGA, Video out: HDMI. Input voltage: 5 V, Power consumption (typical): 1.8 W. Width: 4.84" (123 mm), Depth: 5.35" (136 mm), Height: 1.18" (30 mm)

ATEN VC881. Product color: Black, Housing material: Metal. Maximum video resolution: 3840 x 2160 pixels, Bandwidth: 340 MHz. Host interface: HDMI + DVI, Output interface: HDMI, Audio output: Audio (L, R), Coax, S/PDIF Optical. Power consumption (typical): 1.767 W. Width: 7.95" (202 mm), Depth: 3.34" (84.9 mm), Height: 0.984" (25 mm)

Tripp Lite P130-000-COMP. Converter type: Active video converter, Product color: Black. Supported video modes: 480i,480p,576i,576p,720p,1080i,1080p, Analog signal format system: NTSC,PAL. Host interface: 3 x RCA, Output interface: HDMI. Input voltage: 100 - 240 V, Input frequency: 50/60 Hz, Operating current: 0.3 A. Weight: 21.9 oz (620 g)

ATEN VC160A. Product color: Black. Maximum video resolution: 1600 x 1200 pixels, Supported video modes: 1080p. Host interface: VGA, Output interface: DVI-D. Width: 3.07" (78 mm), Depth: 3.11" (79 mm), Height: 0.957" (24.3 mm). Supported resolutions: 1920x1200

StarTech.com VID2VGATV2. Converter type: Active video converter, Product color: Black, Housing material: Plastic. Maximum video resolution: 1600 x 1200 pixels, Video resolutions: 1024 x 768,1280 x 1024,1600 x 1200, Analog signal format system: NTSC,PAL. Host interface: Composite, S-Video, Output interface: VGA. Operating voltage: 5 V, Operating current: 1 A, Power consumption (typical): 2.5 W. Width: 2.52" (64 mm), Depth: 4.41" (112 mm), Height: 1.02" (26 mm)

StarTech.com HDMI2VGA. Product color: Black. Maximum video resolution: 1920 x 1200 pixels, Supported video modes: 480i,480p,576i,576p,720p,1080i,1080p. Host interface: HDMI, Output interface: VGA. Power requirements: AC 115 - 230 V. Weight: 6.07 oz (172 g)

StarTech.com VID2HDCON. Converter type: Active video converter, Product color: Black, Housing material: Plastic. Maximum video resolution: 1600 x 1200 pixels, Video resolutions: 1024 x 768,1280 x 1024,1600 x 1200, Analog signal format system: NTSC,PAL. Host interface: Composite, S-Video, Output interface: HDMI. Input voltage: 100 - 240 V, Operating voltage: 5 V, Operating current: 1.2 A. Width: 6.42" (163 mm), Depth: 6.46" (164 mm), Height: 1.34" (34 mm)

StarTech.com HDMI2DP. Converter type: Active video converter, LED indicators: Power, Product color: Black. Maximum video resolution: 1920 x 1200 pixels, Maximum refresh rate: 60 Hz. Audio output channels: 5.1 channels. Host interface: HDMI, Output interface: DisplayPort. Input voltage: 100 - 240 V, Operating voltage: 5 V, Operating current: 2 A

Tripp Lite P116-000-HDSC1. Product color: White. Maximum video resolution: 1920 x 1440 pixels, Supported video modes: 720p,1080p, Color depth: 24 bit. Host interface: VGA (D-Sub) + 3.5 mm (1/8"), Output interface: HDMI. Input voltage: 100 - 240 V, Input frequency: 50/60 Hz, Operating current: 0.5 A. Width: 2.2" (55.9 mm), Depth: 2.3" (58.4 mm), Height: 0.902" (22.9 mm)
