APC SMX2000LV uninterruptible power supply (UPS) 2 kVA 1800 W 10 AC outlet(s)1

APC SMX2000LV uninterruptible power supply (UPS) 2 kVA 1800 W 10 AC outlet(s)2

APC SMX2000LV uninterruptible power supply (UPS) 2 kVA 1800 W 10 AC outlet(s)3

APC SMX2000LV uninterruptible power supply (UPS) 2 kVA 1800 W 10 AC outlet(s)4

APC SMX2000LV uninterruptible power supply (UPS) 2 kVA 1800 W 10 AC outlet(s)5

APC SMX2000LV uninterruptible power supply (UPS) 2 kVA 1800 W 10 AC outlet(s)6

APC SMX2000LV uninterruptible power supply (UPS) 2 kVA 1800 W 10 AC outlet(s)7

APC SMX2000LV uninterruptible power supply (UPS) 2 kVA 1800 W 10 AC outlet(s)8

APC SMX2000LV uninterruptible power supply (UPS) 2 kVA 1800 W 10 AC outlet(s)

APC SMX2000LV. Output power capacity: 2 kVA, Output power: 1800 W, Waveform: Sine. AC outlet types: NEMA 5–15R, NEMA 5–20R, NEMA L5-20R, Power plug: NEMA 5-20P, AC outlets quantity: 10 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery recharge time: 3 h. Form factor: Rackmount/Tower, Product color: Black, Rack capacity: 2U. Width: 7.01" (178 mm), Depth: 19" (483 mm), Height: 17" (432 mm)

Manufacturer: APC

SKU: 3598849

Manufacturer part number: SMX2000LV

GTIN: 0731304292586

Products specifications

Attribute name	Attribute value
Width	7.01"
Depth	19"
Height	17"
Weight	85.1 lbs
Battery Recharge Time	3 h
Input Frequency	50/60 Hz
Display	LED
Cable Length	96.1"
Emergency Power Off (EPO)	Yes
Display Type	LED
Compliance certificates	RoHS
Technical details
Product color	Black
Sustainability certificates	RoHS
Packaging data
Package weight	105.2 lbs
Ports & interfaces
AC outlets quantity	10 AC outlet(s)
USB 2.0 ports quantity	1
Power plug	NEMA 5-20P
AC outlet types	NEMA 5–15R, NEMA 5–20R, NEMA L5-20R
Design
Certification	UL 1449
Form factor	Rackmount/Tower
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-15 - 45 °C
Operating relative humidity (H-H)	0 - 95 %
Storage relative humidity (H-H)	0 - 95 %
Operating altitude	0 - 118110.2"
Non-operating altitude	0 - 590551.2"
Power
Nominal input voltage	120 V
Output power capacity	2 kVA
Features
Rack capacity	2U
Output power	1800 W
Noise level	55 dB
Surge energy rating	540 J
Input operation voltage (min)	70 V
Input operation voltage (max)	154 V
Efficiency	97.6 %
Output voltage Total Harmonic Distortion (THD)	5 %
Waveform	Sine
LED indicators	Yes
Audible alarm(s)	Yes
Other features
Output connection type	6 x NEMA 5-15R & 3 x NEMA 5-20R & 1 x NEMA L5-20R
Number of batteries supported	1
Nominal output voltage	120 V
Package dimensions (WxDxH)	23.1 x 24.9 x 13"
Battery
Battery technology	Sealed Lead Acid (VRLA)

Products specifications

Attribute name	Attribute value
Width	7.01"
Depth	19"
Height	17"
Weight	85.1 lbs
Battery Recharge Time	3 h
Input Frequency	50/60 Hz
Display	LED
Cable Length	96.1"
Emergency Power Off (EPO)	Yes
Display Type	LED
Compliance certificates	RoHS
Technical details
Product color	Black
Sustainability certificates	RoHS
Packaging data
Package weight	105.2 lbs
Ports & interfaces
AC outlets quantity	10 AC outlet(s)
USB 2.0 ports quantity	1
Power plug	NEMA 5-20P
AC outlet types	NEMA 5–15R, NEMA 5–20R, NEMA L5-20R
Design
Certification	UL 1449
Form factor	Rackmount/Tower
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-15 - 45 °C
Operating relative humidity (H-H)	0 - 95 %
Storage relative humidity (H-H)	0 - 95 %
Operating altitude	0 - 118110.2"
Non-operating altitude	0 - 590551.2"
Power
Nominal input voltage	120 V
Output power capacity	2 kVA
Features
Rack capacity	2U
Output power	1800 W
Noise level	55 dB
Surge energy rating	540 J
Input operation voltage (min)	70 V
Input operation voltage (max)	154 V
Efficiency	97.6 %
Output voltage Total Harmonic Distortion (THD)	5 %
Waveform	Sine
LED indicators	Yes
Audible alarm(s)	Yes
Other features
Output connection type	6 x NEMA 5-15R & 3 x NEMA 5-20R & 1 x NEMA L5-20R
Number of batteries supported	1
Nominal output voltage	120 V
Package dimensions (WxDxH)	23.1 x 24.9 x 13"
Battery
Battery technology	Sealed Lead Acid (VRLA)
